Description

Material
Body QT steel.
Tension lever QT steel.
Version
Body black oxidized.
Clamping face ground.
Tension lever style B black oxidized.
Tension lever style C nickel-plated.
Note
Tighten the setscrew to prevent the side clamp sliding back during the clamping process. (style A)

The tension lever can be
user-friendly aligned horizontally and vertically in 90° increments by loosening the grub screw.

The workpiece can be clamped with a constant clamping force through the integrated surface on the style C tension lever.
Advantages
- High clamping force
- Ground clamping face
- Pull-down force prevents the workpiece lifting
Drawing reference
1) Setscrew
2) Cap screw
3) Grub screw
4) Loosened position
5) Clamping travel
6 )Clamping start position
7) Clamped position
