- Application sectors: machine, instrument and fixture construction, measuring technology, domestic use
- Locked by actuating the push button
- Release button allows adjustment of the locking position
Description
Material
Steel version:
threaded sleeve and indexing pin, steel.
Stainless steel version:
indexing pin not hardened.
Threaded sleeve and indexing pin 1.4305.
Mushroom grip, black grey thermoplastic.
Release button, red thermoplastic.
Version
Steel version:
threaded body, black oxidized.
Indexing pin hardened, ground and black oxidized.
Stainless steel version:
threaded body, bright.
Indexing pin not hardened, ground and bright.
threaded body, black oxidized.
Indexing pin hardened, ground and black oxidized.
Stainless steel version:
threaded body, bright.
Indexing pin not hardened, ground and bright.
Note
Indexing plungers are used where any change in locking position due to lateral forces should be prevented.
The locking mechanism is activated by pressing the push button.
The red release button enables the indexed position to be changed.
The locking mechanism is activated by pressing the push button.
The red release button enables the indexed position to be changed.
